Nordson EFD PICO Touch User Manual

PICO Toµch Controller
27www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
1
PICO Toµch controller
2
Power cord, American plug, Toµch controller, 2 m (6.6 ft)
3
Cable, USB, A male to B male, 2 m (6.6 ft)
4
Backshell, I/O, 15 position, D-sub
5
Connector, I/O, 15 position, D-sub
6
Power supply, Toµch controller, 1 m (3.3 ft)
7
PICO Pµlse valve (ordered separately)
8
Extension cable (optional)
(Not shown)
Welcome letter
Quick start guide
1
2
3
4
5
Installation
Use this section in tandem with the quick start guide and any other system component operating manuals to install
all components of the system.
Unpack the System Components
6
7
8

Nordson EFD PICO Touch Specifications

General

Brand	Nordson EFD
Model	PICO Touch
Category	Controller
Language	English
