PICO Toµch Controller
49www.nordsonefd.com info@nordsonefd.com 800-556-3484 Sales and service of Nordson EFD dispensing systems are available worldwide.
Pin
Number Pin Name Direction Level Description
6 Not available Nordson EFD use only
7 DGND Internal non-isolated ground for use with RS232
8 Not available Nordson EFD use only
9 Not available Nordson EFD use only
10 Not available Nordson EFD use only
11 Not available Nordson EFD use only
12 Not available Nordson EFD use only
13 DGND Internal non-isolated ground for use with RS232
14 Not available Nordson EFD use only
15 DGND Internal non-isolated ground for use with RS232
16 Not available Nordson EFD use only
17 DSUB_GND External ground
18 Not available Nordson EFD use only
19 DSUB_GND External ground
20 Not available Nordson EFD use only
21 DSUB_GND External ground
22 Not available Nordson EFD use only
23 Not available Nordson EFD use only
24 Not available Nordson EFD use only
25 Ext 24 Volts Input/output 24V The controller can provide up to 200 mA as a courtesy power
supply or this pin can be used to provide an external isolated
power supply. Use the “dioe”and “dioi” commands to congure
the functionality of this pin (Refer to "Appendix A, Remotely
Operating the Controller" on page 53). Contact Nordson EFD
for applications which require more than 200 mA.
Input / Output Port Pin Descriptions (continued)
I/O 2 25-Position D-Sub (continued)
