System Overview
2-1
Part 1618871−01
2020 Nordson Corporation
Section 2
System Overview
This manual covers the system controls hardware for Encore
Engage
system controllers.
NOTE: The system also requires external part ID sensors such as
photoeyes or scanners for part identification and zone detection.
See Figure 2-1. The following Encore Engage controllers are available:
Encore Engage Main System Controller − Includes touchscreen
controls and supports 4−16 powder spray guns
Encore Engage System Controller with Remote Interface
Controller − Supports 4−16 powder spray guns with remote controller
for interface controller mobility
Encore Engage Auxiliary Controller − Provides support for adding an
additional 2−16 spray guns
Encore Engage
Main System Controller
Encore Engage
Auxiliary Controller
Encore Engage Main System
with Remote Controller
Figure 2-1 Encore Engage Controllers
