System Overview
2-10
Part 1618871−01
2020 Nordson Corporation
Main and Auxiliary Cabinet Dimensions
625 mm
(25 in.)
1807.5 mm
(71 in.)
607.6 mm
(24 in.)
392 mm
(15 in.)
196 mm
(8 in.)
R616
DOOR
OPENING
6X 10.0
550 mm
(22 in.)
10019246
Figure 2-7 Main and Auxiliary Cabinet Dimensions (shown with main cabinet)
