Installation
3-3
Part 1618871−01
2020 Nordson Corporation
Interconnect Cables
Table 3-1 System Interconnect Cables
Cable Function Type
P1 AC Switched/Unswitched 7 Conductor 8A Maximum, 1.25 in. mini
P2 Enet 2 (Nord Network) M12 D Coded Female E-net
P3 Remote AC Power Source 4A Fused, 200VA Maximum
P4 Manual Gun Connection (CAN 1) CAN +24 V
P5 Auxiliary Automatic Cabinet Connection
(CAN 2)
CAN Network/Lockout
P6 HDLV Pump M12 Conductor Cable, 12 Conductor
P7 Air Conditioner Power
⅞-in. mini
P8 E-stop 4 Conductor M12
P9 Enet 3 (Remote Screen) M12 D Coded Female E-net
P11 WAN (Customer Data) M12 D Coded Female E-net
PC1 Interlock/Alarm (Optional) 1.25 in. mini
PC2 Encoder 4 Conductor M12
To Next Page
