System Overview
2-7
Part 1618871−01
2020 Nordson Corporation
Specifications
General
See Figures 2-8 and 2-7 for pedestal and console dimensions.
Electrical Requirements
Input
100−230 Vac, 50−60 Hz, 1 ∅, 500VA max.
Switched: 500VA
Unswitched: 300VA
Conveyor Interlock, Remote Lockout: 120/230 Vac, 50/60 Hz, 1 ∅, 6 mA
Alarm Relay contact rating: 120/230 Vac, 1 ∅, 60 W
Output (to spray gun) ± 19V, ±1A (peak)
Output (remote display) 200VA max.
NOTE: The Engage system must be interlocked with the fire detection system so that the spray guns are
shut off if a fire is detected inside the spray booth.
ANSI/ISA S82.02.01
Pollution Degree 2
Installation (Overvoltage) Category II
Environmental
Operating Temperature
+15 C to +40 C
Operating Humidity 5−95%, non-condensing
Environmental
Weight (fully populated main
controller)
345 lb (156 kg)
Note A: Branch circuit breaker 8A Max.
Pump and Spray Gun Pattern Air Quality
Air must be clean and dry. Use a regenerative desiccant or refrigerated air
dryer capable of producing a 3.4
o
C (38
o
F) or lower dew point at 7 bar
(100 psi) and a filter system with prefilters and coalescent-type filters
capable of removing oil, water, and dirt in the submicron range.
Recommended Air Filter Screen Size: 5 micron or smaller
Maximum Oil Vapor in Air Supply: 0.1 ppm
Maximum Water Vapor in Air Supply: 0.48 grains/ft
3
Moist or contaminated air can cause the pumps to malfunction; the powder
to cake in the reclaim system, or cause clogging in the feed tubing or spray
gun powder paths.
