System Overview
2-11
Part 1618871−01
2020 Nordson Corporation
Remote Controller Touchscreen Interface
704 mm
(28 in.)
564 mm
(22 in.)
414 mm
(16 in.)
256 mm
(10 in.)
287 mm
(11 in.)
10019168
Figure 2-8 Remote Controller Touchscreen Interface Dimensions (shown with optional E-stop extention)
