Fulfill
Retrofit for Mesa Melters
29
Part 1121938_02
2013 Nordson Corporation
Monitoring Refill Operation
See Figure 16.
Under normal conditions, the operator need not monitor or intervene in the
operation of the fill system.
However, if the fill system is unable to satisfy the tank sensor in the time limit
set for the Fill Time, the refill alarm LED will illuminate. Refer to
Troubleshooting for a list of possible fault causes and solutions.
1
2
3
4
Figure 16 Fill system controls and indicators
1. Enable On/Off
2. Filling activated symbol and blue LED
3. Fault symbol and red LED
4. Clear fault
Maintenance
Inspect the system daily to ensure that hose fittings are secure and that the
unit is free from dirt and debris. Inspect the filter sock weekly to ensure that
it's not clogged; replace as needed.
