RetroFit Refill System with Nordson Level Sensor
A-12
Part 1121938_02
2013 Nordson Corporation
Installation
Common Chassis Connection
CAUTION! Failure to install a wired connection as described below will
cause the Fulfill unit to not function.
There must be a wired connection between the Retrofit box chassis and the
melter chassis for stable operation. This connection is normally made from
the Refill PCA ground tab to the quick connect tab on the Retrofit mounting
bracket, but any terminal on the Refill PCA labeled “COM” can be used to
connect to the melter chassis.
Service Parts
Part Description
1121799 Kit, service, power cable, MKIII PB FF Retrofit
1121800 Kit, service, power supply, Fulfill
1121802 Kit, service, Nordson sensor, 150 mm, Fulfill retrofit
1121804 Kit, service, PCA, MKIII Fulfill
1121406 Harness, Line in, Retrofit
1121491 Harness, 24 VDC, Retrofit
1121492 Harness, siren, Retrofit
1121493 Harness, low level
1121599 Harness, T.B. Plug, jumpered, Retrofit
1121794 Harness, AC, unit powered, Retrofit
1105320 Splitter, power supply, FM, sensor, 16 AWG
1121818 Control box assy, Fulfill Retrofit
1120695 Alarm, audible, panel mount, 24 VDC
1099525
Kit, membrane panel, Fulfill Retrofit
1121806 Kit, light tower
