Fulfill
Retrofit for Mesa Melters
34
Part 1121938_02
2013 Nordson Corporation
Lid Assembly Parts
See Figure 17.
Item Part Description Quantity
1101214 Lid assy, Mesa 4 Fulfill retrofit
1101215 Lid assy, Mesa 6 Fulfill retrofit
1101216 Lid assy, Mesa 9 Fulfill retrofit
1101217 Lid assy, Mesa 14 Fulfill retrofit
1 1095342
Enclosure assy, filter, lid, Fulfill
1
2 1088282
Filter, sock, 200 micron, Fulfill
1
3 982374
Scr, skt, M5X40, bl
4
4 1096978
Collar, lid, Fulfill
1
5 1097018
Tube, exhaust, Fulfill
1
6 1097866
Retainer, filter housing, Fulfill, 3000
1
7 1101226
Cover, Mesa 4 lid, Fulfill retrofit
1
7 1101227
Cover, Mesa 6 lid, Fulfill retrofit
1
7 1101228
Cover, Mesa 9 lid, Fulfill retrofit
1
7 1101229
Cover, Mesa 12 lid,Fulfill retrofit
1
8 1097663
Spacer, lid, Fulfill retrofit
1
9 1101222
Insulation, Mesa 4 Fulfill retrofit
1
9 1101223
Insulation, Mesa 6 Fulfill retrofit
1
9 1101224
Insulation, Mesa 9 Fulfill retrofit
1
9 1101225
Insulation, Mesa 14 Fulfill retrofit
1
10 1101218
Lid,inner, Mesa 4 Fulfill retrofit
1
10 1101219
Lid,inner, Mesa 6 Fulfill retrofit
1
10 1101220
Lid, inner, Mesa 9 Fulfill retrofit
1
10 1101221
Lid, inner, Mesa 14 Fulfill retrofit
1
11 1099398
Baffle, 3000 Fulfill retrofit
1
12 982780
Scr, skt, M5X10, ZN
4
13 1099399
Deflector, 3100 Fulfill retrofit
1
14 1097016
Tube, inlet, Fulfill
1
15 983163
Washer, flt, M, oversized, M4, zn
1
16 982025
Scr, skt, M4X14, bl
3
17 1098021
Knob, black plastic with M5 X 30 lg stud
3
NS 983408
Washer, flt, M, narrow, M5, stl, zn
3
NS 940073
O ring, Viton, .145ID X .070W .BR, 10407
3
NS: Not Shown
