Nordson Mesa Fulfill User Manual

Fulfill

Retrofit for Mesa Melters
38
Part 1121938_02
 2013 Nordson Corporation
Control Box Assembly
See Figure 19.
Item Part Description Quantity
— 1098169 Control box assy, Fulfill retrofit −−−−−−
1 1097912
 Enclosure, poly, machined
1
2 982360
 Scr, skt, M3X10, zn
4
3 983520
 Washer, lk, M, int, M3, stl, zn
4
4 982604
 Scr, panhd, thd form, M4X12, bl
4
5 982780
 Scr, skt, M5X10, zn
1
6 983401
 Washer, lk, M, spt, M5, stl, zn
1
7 230261
 Termlug, ground, 6−14 AWG
1
8 982157
 Scr, skt, M3X14, B
1
9 933747
 Block, terminal, 2 station
1
10 1098483
 Domeplug, .500 in. D, .250 in. pnl thk
2
11 1099525
 Membrane panel
1
12 1097950
 Panel, mtg, ckt. bd.
1
13 1094486
 Block, heat sink, Easy−Pac
1
14 1054073
 Scr, skt, hd, M3x20 mm, steel, zn
1
15 1096221
 PCA, refill controller
1
16 1098484
 Domeplug, .750 in.D, .250 in. pnl thk
1
17 1046998
 Connector, strain relief, PG7, nylon
2
18 933607
 Connector, strain relief ,PG11
1
19 1098475
 Harness, AC power
1
