Nordson Mesa Fulfill - Control Assembly with Bracket

Fulfill

Retrofit for Mesa Melters
36
Part 1121938_02
 2013 Nordson Corporation
Control Assembly with Bracket
See Figure 18.
Item Part Description Quantity Note
— 1101838 Control box/reg. assy, 3000 Fulfill −−−−−−
1 1101502
 Bracket, reg. assy, 3000, Fulfill
1
2 1093650
 Valve, solenoid, 3−way, 24V,
1
/
4
NPT
1
3 972125
 Conn, male, elbow, 10mm T X
1
/
4
uni
1
4 1040003
 Scr, skt, M4x25, zn
2
5 1096668
 Regulator/filter, 40 mic,
1
/
4
NPT, 65 psig
1
6 1101987
 Kit, service, level sensor, Fulfill
1
7 233785
 Elbow,male,
1
/
4
NPT
1
8 982059
 Scr, skT, M4X8, bl
2
9 1058059
 Muffler polyethylene
1
/
4
NPT, Saturn
1
10 1099250
 Holder assy, leve;l probe
1
11 271221
 Lug, 45, double, .250, .438
1
12 983401
 Washer, lk, M, spt, M5, st, zn
1
13 982780
 Scr, skt, M5 x 10, zn
1
14 983021
 Washer, flt, E, .203 x .406 x .040, br
1
15 1098169
 Control box assembly
1 A
16 1101397
 Bracket, control box,
1
17 1098106
 Knob, black plastic, M5 x 10
1
18 1101395
 Bracket, control
1
19 1101398
 Bracket, nut bar
1
20 982680
 scr, hex, washhd, tf, M5 x 12, blk
4
21 306005
 Wire mount, cable strap, 4 way
1
22 939110
 Cabletie, 3.9 in., nylon
6
23 1101099
 Harness assy, solenoid, 3.5 ft
1
NOTE A: Parts for the control box are provided later in this section.
