Nordson Mesa Fulfill User Manual

Fulfill

Retrofit for Mesa Melters
33
Part 1121938_02
 2013 Nordson Corporation
Mesa Retrofit Kit Assemblies
Item Part Description Quantity Note
------- 1101880 Kit, Fulfill retrofit, Mesa 4
------- 1101881 Kit, Fulfill retrofit, Mesa 6
------- 1101882 Kit, Fulfill retrofit, Mesa 9
------- 1101883 Kit, Fulfill retrofit, Mesa 14
1 1101838
 Control box / reg.assy,Mesa Fulfill
1 A
2 1101214
 Lid assy, Mesa 4, Fulfill retrofit
1 B
2 1101215
 Lid assy, Mesa 6, Fulfill retrofit
1 B
2 1101216
 Lid assy, Mesa 9, Fulfill retrofit
1 B
2 1101217
 Lid assy, Mesa 12, Fulfill retrofit
1 B
3 1101859
 Kit, ship w/, fasteners, Fulfill Mesa, retro
1
4 11101837
 Harness, sensor, ground, Mesa Fulfill
1
NOTE A: Further listing provided in Control box/regulator table provided later in the Parts section.
B: Further listing provided in Lid Assembly table provided later in the Parts section.
Ship With Fastener Kit
Part Description Quantity
984706A Nut, hex, M5, stl, zn 2
983401A Washer, lk, M, spt, M5, stl, zn 2
982594A Scr, skt, M4 X 10mm, bl 4
983402A Washer, flt, M, narrow, M4, stl, zn 4
1094834A Standoff, m/f, 10mm hex, M5 thd, stl/zinc 3
1017010A Scr, btn, skt, M5 X 10, bl 3
982202A Scr, btn, skt, M5 X 25, zn 2
983418A Washer, flt, M, oversized, 5, stl, z 2
