Nordson Mesa Fulfill User Manual

Fulfill

Retrofit for Mesa Melters
41
Part 1121938_02
 2013 Nordson Corporation
Specifications
Parameter Specification
Adhesive Forms
Maximum size
Pellets, pastilles, mini-slats
 Pastilles: 12 mm (0.472 in.) diameter
 Mini‐slats:
12 mm X 12 mm (0.472 in. X 0.472 in.) in length
Input voltage 100−240/1 VAC, 1 A
Power cord Customer supplied, 14−18 AWG
Adhesive Transfer Maximum Rate 227 kg (500 lb)/hour (dependent on adhesive type)
Transfer Hose Length 4 m (13 ft)
Operating Air Minimum 4.5 bar (0.45 MPa or 65 psi)
Maximum 8.6 bar (0.86 MPa or 125 psi)
Total Air Consumption 679 Liters/min (24 SCFM) when feeding
Conditioning Dry, non−lubricated
Inlet Air Connection
1
/
4
in. NPT female
1
/
4
BSPP female
G
1
/
4
female
Pump Type Venturi
Noise Emission 76 dBA
Suction Lance Dimensions (L) 615 mm x max (W) 105 mm
(24.21 in. x max 4.14 in.)
Storage Bin Capacity 60 Kg (132 lb)
Enclosure rating IP54
