Chapter 38 Termination or sparing panel replacement 201
Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2
Figure 53
Termination or sparing panel replacement task flow
Yes
Single
Modular
No
Termination or sparing
panel replacement
Switching between
active and
standby
processor cards
Switching between
active and
standby
processor cards
Temporarily
disabling an LP
MSA32?
Removing a
termination panel
Installing a
termination panel
Re-enabling an LP
Removing a
cabinet door
(optional)
Removing a
cabinet door
(optional)
Removing an
MSA32 sparing
panel cable cover
(if necessary)
Removing a
termination panel
Installing a
termination panel
Installing an
MSA32 sparing
panel cable cover
(if necessary)
Installing a
Multiservice
Switch cabinet
door
(if necessary)
Single or
modular?
Installing FP
cables
Installing FP
cables
End
For procedure page
numbers, see
Task flow navigation
below
PP_TASK_1018
