Chapter 39 Hardware procedures 247

Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2

Figure 76

Cabinet door alarm connector

Alarm cutoff

control

Door alarm

connector

Trough for

door alarm

cable
