248 Chapter 39 Hardware procedures

NN10600-175 6.1S2

Figure 77

Multiservice Switch 7480 alarm connectors

PPT 2179 001 AA

Door alarm

connector

Cooling unit

power connector

Alarm 1

external alarm

connector

Alarm 2

shelf connector

Shelf

interconnect

cable
