258 Chapter 39 Hardware procedures

NN10600-175 6.1S2

Procedure job aid

Figure 82

The cooling unit of a Multiservice Switch 7460 with its air filter

PPT 3479 001 AA3

Status LED

Faceplate

Front airflow grill

Captive screw

Cooling unit

Air filter P0609614

Power input

connector

Fan number 4
