Chapter 39 Hardware procedures 259

Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2

Figure 83

Exploded view of the cooling unit and a Multiservice Switch 7460

Shelf assembly

Intake airflow

grill

PPT 3479 009 AA2

Cooling unit

Captive screw
