Chapter 39 Hardware procedures 341

Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2

Procedure job aid

Figure 125

Terminal block for the dc power cables of an Multiservice Switch 7460

PPT 3479 003 AA

RTN

PS2

RTN-BAT-BAT

Stud for a

1-hole lug

Mounting ear

Insulation

shield

Shelf assembly

PS1

Grounding

stud
