342 Chapter 39 Hardware procedures

NN10600-175 6.1S2

Figure 126

Terminal block dc cable connections for an Multiservice Switch 7460

PPT 3479 014 AA

Terminal

block

Post to fasten

insulation shield

Shelf assembly

Grounding stud

PS2

-BAT

PS2

RTN

PS1

-BAT

PS1

RTN

Green and

yellow cable

with 1-hole lug

1-hole lug
