384 Chapter 39 Hardware procedures

NN10600-175 6.1S2

Procedure job aid

Figure 141

Cabinet door with hinges on the left

PPT 1044 001 AA

Door latch

Door alarm

indicator cable

Lower hinge

Hinge supporting

plates

Top and

centre hinges

Blank door latch
