Installation guidelines
3-35
User Guide Rel 1.0 Standard May 1999
Procedure 3-11 (continued)
Connecting ac power
Step Action
3
Make sure all the breakers on the ac distribution box are in the OFF position.
4
Remove the breaker box cover by removing the screw.
5
Verify that the power is not present on the ac power leads.
6
Route the ac power leads (L1, L2, N, and Gnd) from the external ac power
source though the conduit at the bottom of the ac distribution box.
7
Connect the L1 and L2 leads on the L1/L2 line lugs.
8
Connect the N lead to the neutral bus bar.
9
Connect the Gnd lead to the ground bus bar.
10
Replace the cover.
11
Tighten the screw.
12
Fill the opening around the commercial power cables at the cutout, use B
sealant tape or other filler according to local practices.
13
Close and secure the power AC compartment door.
14
Continue the cabinet installation process (see Procedure 3-12, “Installing
batteries”).
—end—
CAUTION
Ensure that the screw or jumper intended to connect the
neutral bar to the ground bar in the AC load center is
removed and discarded.
