2-48
Equipment
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Repeater/span DS1 termination facilities
DS1 termination facilities are provided by up to two 28-position repeater
shelves.
DS1 lines IN are terminated with powering or bridging repeater modules or
cut-through repeater modules as required.
The repeater shelves are equipped with a fuse and alarm module for power
protection of the modules and fuse alarm generation/transport to the alarm
reporting section of the BIP.
Mechanical specifications
Table 2-2 lists the mechanical specifications for the AN2016 Cabinet.
Table 2-2
Mechanical specifications
Feature Specification
Construction folded aluminum of 0.125 inch thick, allow 5052 with
TGIF polyester powder coat finish
Colors & Finish TGIC polyester powder coat with a textured finish,
off-white paint, per Munsell Y 7.3 8.1
Access • double front door
• double rear door
• side door to SPC and termination compartment
• side door to AC compartment
• battery compartment
Note 1:
The doors have concealed hinge pins.
Note 2:
The doors are weather sealed.
Cable entry by openings in the bottom of the cabinet
Note:
You must seal cable conduits to prevent water
entry. You must apply a plug compound on and around
all conduit openings.
Door locks a multi-point locking mechanism operated by a handle
and equipped with padlock
Roof equipped with four steel eye bolts for lifting and
installing cabinet
