6-40
Ordering information
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Table 6-14 lists the required options for a 2016-line cabinet.
Optional equipment
The AN2016 Cabinet CDS configuration allows popular options to be
installed.
Table 6-15 lists the optional cross- connect equipment for an AN2016 Cabinet.
Ta bl e 6- 16 lists the optional transport and loop extender kits for the AN2016
Cabinet.
Table 6-17 lists the optional fiber manager kits for the AN2016 Cabinet.
Table 6-18 lists the optional remote monitoring unit (RMU) and associated
cable assembly for the AN2016 Cabinet.
Table 6-19 lists the optional battery backup and associated cable assembly for
the AN2016 Cabinet.
Table 6-20 lists the optional 100 Amp power pedestals and associated
mounting templates for the AN2016 Cabinet.
Table 6-21 lists the optional optical patchcord assemblies and protector
modules for the AN2016 Cabinet.
The options listed Table 6-15 in through Table 6-21 are fully packaged to fit
the cabinet and include a cable harness. The following kits can be ordered
separately based on the engineering rules provided with the table.
Note: All OEM equipment can be installed as required, however, special
configurations out of the ones provided or other OEM equipment request
must be confirmed to allow future expansions of the cabinet, especially
with copper distribution shelves.
Table 6-14
AN2016 Cabinet 2016-line required options
CPC PEC Description Quantity
B01231144 NT5C06CA-3 MPR 25 rectifier module (see Notes 1 and 2) 4 or 5
Note 1:
Insert appropriate number of modules into rectifier shelves NT5C10CP-61 part of NTNR21AA.
Note 2:
Order (1) MPR 25 for each AN hardware (672L) + (1) for each OEM stack + (1) for redundancy.
Note 3:
Four modules total are required for 2016 lines + (1) for redundancy.
Note 4:
Refer to “Optional battery backup” on page 6-45 for ordering battery string hook up cables,
required when the battery compartment holds the battery backup.
Note 5:
Refer to “ Optional remote monitoring unit” on page 6-44 for ordering RMU test access path
cable when optional RMU NTNR35AA is selected. A cable must be ordered for each additional AN ABM
NTNR10AA.
