Ordering information
6-47
User Guide Rel 1.0 Standard May 1999
Table 6-21 lists the optional optical patchcord assemblies and protector
modules for the AN2016 Cabinet.
CPC Description Quantity
A0784389 Voltage surge arrestor for AN2016, ac load center in AC compartment
Note 1:
Order if power pedestal is not equipped with Surge arrestor.
Note 2:
Order if power pedestal is located more than five feet away from
the AN2016 cabinet.
1
—end—
Table 6-21
Optional optical patchcord and protector modules
CPC PEC Description Quantity
A0365303 NT7E46BA Optical patchcord cable assembly, FC-FC type 2
A0351099 NT7E46CA Optical patchcord cable assembly, ST-ST type 2
A0408374 NT7E46FA Optical patchcord cable assembly, SC-SC type 2
Note 1:
Provide two NT7E46BA, CA OR FA depending of connector type per Optical circuit pack
provided in the AN ABM shelf, when connecting to a fiber manager kit NTNR34AA.
Note 2:
Length of 5 meter, MVOA is not required.
A0358876 NT7E47BA Optical patchcord cable assembly, FC-FC type 2
A0358877 NT7E47CA Optical patchcord cable assembly, ST-ST type 2
A0408379 NT7E47FA Optical patchcord cable assembly, SC-SC type 2
Note 1:
Provide two NT7E47BA, CA OR FA depending of connector type per Optical circuit pack
provided in the AN ABM shelf, when connecting to a fiber manager with MVOA required.
Note 2:
Length of 5 meter, MVOA is provided.
A0341959 303M-11A1GO Protector module VF 5 pins gold plated, black, solid
state OVP, 300 V
1 per VF line
see Note
A03411961 303M-11A1TO Protector module VF 5 pins tin plated, black, less heat
coils
1 per VF line
see Note
A0353718 303M-12A1TA Protector module VF 5pins tin plated, solid state, 350
mA heat coils
1 per VF line
see Note
Note:
Provide one per VF: 672 for 7 CDS, 864 for 9 CDS, 1344 for 14 CDS and 2016 for 21 CDS.
—continued—
Table 6-20 (continued)
Optional 100 Amp power pedestals and accessories
