Equipment
2-13
User Guide Rel 1.0 Standard May 1999
AC load center
The AN2016 cabinet is equipped with an eight position AC load center with
one 100 A back fed main 2-pole circuit breaker, two 2-pole 40 A circuit
breakers with 8 american wire gauge (AWG) in 3/4 inch conduit for dc power
plant, one 15 A 1-pole circuit breaker for convenience outlets, and one 20 A
1-pole circuit breaker for battery heater pads.
Table 2-1 lists the AC load center circuit breakers and their ratings.
For an illustration of the front view of the AC load center, see Figure 2-8.
Table 2-1
Circuit breakers designations and ratings
Designation Amperage
Main 100
CB2 (Rectifier #1) 40
CB3 (Rectifier #2) 40
CB4 (GFI) 15
CB5 (Heaters) 20
