Equipment
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
• copper-distribution shelf (CDS)
• fan shelf
For detailed information regarding the AccessNode equipment descriptions,
reference Configuration and Equipment Description, 323-3001-100, in
Description, Volume 2A.
The following sections describe the AccessNode equipment.
Equipment layout
The equipment shelves described in this section mount in the front-side of the
frame/bays (A, B, C, D, E and F).
Figure 2-21 shows the equipment layout and shelf positions of frame/bay E in
the cabinet equipment compartment.
