2-6
Equipment
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Doors
Six doors enable you to access the AN2016 cabinet:
• one each for the SPC and AC compartments
• two sets of double doors for the equipment compartment
The equipment compartment is accessible through overlapped hinged outside
doors. You can access the battery compartments and end compartment
kickplates from the equipment compartment or the end compartment.
Door locks
All hinged exterior doors are designed to be locked through a multi-point
locking mechanism to ensure that all door corners and edges are secure. The
locking mechanism contains a padlock hasp that can accept a 1/4 inch diameter
padlock shackle.
When the door locks are enabled, the front and rear equipment, the AC, and
the SPC and termination compartment doors can be opened with a 216-type
socket tool.
Note: Each door locking mechanism is disabled at the factory prior to
shipment.
The door locking mechanism prevents water intrusion into the cabinet.
Intrusion and system failure alarms are provided to a remote alarm monitoring
center. A local intrusion alarm is provided to work in conjunction with the
remote alarm.
Cable access ports
Four cable access ports are provided in the base of the surge protection center
(SPC) and termination compartment. These ports have 4 inch (10.16 cm)
inside diameter split-sleeve openings which facilitate the entrance of metallic
and optical fiber cables. One 1/2 inch (12.7 mm) grommet opening is also
provided for grounding purpose.
Two additional cable access ports are provided in the base of the AC
compartment. These ports have 4 inch (10.16 cm) inside diameter split-sleeve
openings. One 2 1/2 inch (63.5 mm) opening is provided for ac conduit.
Cable entrance seals prevent water intrusion into the compartments.
