Procedure 5-8
Connecting the fan shelves to the ECU
Use this procedure to connect the fan shelves to the environmental control unit
(ECU).
Action
Step Action
1
Turn off power to the ECU by turning the appropriate circuit breaker to the off
position (see Figure 2-29).
2
Make sure there is no power supplied to the ECU.
3
Remove the screws that connect the ECU to the heat exchanger vent.
4
Lift the ECU with caution up away from the vent. Disconnect and remove the
ECU (see Figure 5-10).
5
Connect the fan shelf connectors to the ECU (see Figure 5-11 and table 5.2).
6
Reinstall the ECU.
7
When all work is complete, apply power to the ECU.
8
To verify the operation of the ECU, refer to the start up and initialization
routine, see Procedure 5-7, ”Starting up the ECU”.
—end—
