6-48
Ordering information
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Recommended replacement parts
Table 6-22 lists the recommended replacement parts for the AN2016 Cabinet.
CPC PEC Description Quantity
A0341960 303M-11A3GO Protector module DS1, gold plated pin, red, less heat
coils
2 per DS1
line see Note
A0341962 303M-11A3TO Protector module DS1, tin plated pin, red, less heat
coils
2 per DS1
line see Note
A0353719 303M-12A3TA Protector module DS1, 5 pins tin plated, solid state,
350 mA heat coils.
2 per DS1
line
Note:
Provide two per DS1: example a quantity of 56 for ADC Soneplex or DDM+ shelves.
—end—
Table 6-22
Replacement parts
CPC PEC Description Quantity
A0341959 303M-11A1GO Protector module VF 5 pins gold plated, black,
solid state OVP, 300 V
10
A0341960 303M-11A3GO Protector module DS1, gold plated pin, red, less
heat coils
10
A0341961 303M-11A1TO Protector module VF 5 pins tin plated, black, less
heat coils
10
A0341962 303M-11A3TO Protector module DS1, tin plated pin, red, less
heat coils
10
A0353718 303M-12A1TA Protector module VF 5 pins tin plated, solid state,
350 mA heat coils
10
A0353719 303M-12A3TA Protector module DS1, 5 pins tin plated, solid
state, 350 mA heat coils
10
A0108992 Fuse 2 A GMT, used in DSX cross-connect
NTNR30AA, environmental control unit (ECU)
main circuit and fan circuit
As required
A0108995 Fuse 5 A GMT, fan shelves fuses As required
A0109762 Fuse 10 A GMT, heat exchanger fuses As required
P0622488 Fuse cover, used for the above fuses As required
—continued—
Table 6-21 (continued)
Optional optical patchcord and protector modules
