3-24
Installation guidelines
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Procedure 3-7
Leveling the cabinet
Use this procedure to level the AN2016 Cabinet and align the doors.
Requirements
You need the following tools and materials:
• socket wrench set
• spirit level, 24 in. (610 mm)
Action
Step Action
1
Open the cabinet doors and locate the spacer kit supplied with the cabinet in
the battery compartment. Set the spacer kit aside.
2
Close and secure all cabinet doors.
3
Remove the alignment bracket and spacers from the spacer kit.
4
Attach the bracket to the insert on the cabinet base nearest the lower hanging
door (see Figure 3-18).
5
Use a spacer as a supporting plate for the adjustment bolt. Turn the
adjustment bolt on the alignment bracket to raise the cabinet base and door.
6
Determine the correct number of spacers. Fit spacers between the cabinet
base and the rubber base pad until the doors are evenly aligned.
7
Raise the cabinet a turn or two higher to create clearance for the spacers.
Insert the correct number of spacers under the corner of the cabinet base
adjacent to the alignment bracket.
8
Insert the long spacers under the battery compartment where required.
9
Put the spacers in position and turn the adjustment bolt on the alignment
bracket to lower the cabinet on to the spacers. Make sure the doors maintain
their alignment.
10
Repeat the previous steps until the doors are aligned. When the doors are
aligned, remove the alignment bracket.
11
Check the alignment of the other doors. If the doors are not aligned, attach
the alignment bracket to the insert as described in this procedure and add
spacers as necessary.
12
Verify that each door switch operates normally.
13
Continue the cabinet installation process (see Procedure 3-6, “Mounting the
cabinet on the pad”, step 7).
—end—
