Additional information
For more information about AccessNode operating specifications, refer to
Configuration and Equipment Description, 323-3001-100, in the AccessNode
library.
Power and grounding
The AN2016 Cabinet operates from a standard 120/240 V ac, 100 A,
single-phase, 3-wire commercial power supply. All ac wiring must conform to
National Electric Code standards.
Alternating current power entrance
The AN2016 Cabinet meets all specifications required by a commercial or
emergency power source. These specifications support ac voltage variation of
190–253 V ac (between Line 1 and Line 2, standard setting), with a frequency
of 55–65 Hz. For more information, refer to Bellcore Family of Requirements,
FR-440, Functional criteria for digital loop carrier systems, Issue 02, January
1997, TR-NWT-000057.
Direct current power requirements
A modular power rectifier provides power to the AN2016 Cabinet. The
rectifier features extensive alarm monitoring and an LVD unit.
Environmentally induced
vibration
GR-487-CORE, section 3.41
Electromagnetic interference
(EMI) for ECU
GR-1089-CORE, section 3 (all, see also Note
2), Class A devices
Electrostatic discharge for ECU GR-1089-CORE, section 2
Radiated emissions for AN2016 FCC, part 15, class A
Note 1:
The alarms include door intrusion and high temperature alarms.
Note 2:
Section 3.27 applies to sealed cabinets only.
—end—
Table 2-9
