1-2
Cabinet introduction
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Table 1-1 shows the compartments and the contents of each.
Applications
The AN2016 cabinet is designed for a wide range of serving areas such as:
• residential and multi-family complexes
• high traffic commercial areas that require
— special service lines
— high-capacity digital service
— direct fiber access
The cabinet delivers flexible solutions and comprehensive services required
for concentrated commercial growth areas such as:
• commercial and industrial business parks
• high-tech business corridors and retail malls
Basic cabinet configuration
The basic AN2016 cabinet system consists of the following items:
• AccessNode fiber-optic based network system
• ac and dc power distribution
• environmental controls
• a rectifier/battery charger
• optional battery backup
• surge protection center (SPC) that provides primary protection for VF
(DS0 lines) and high frequency (HF) pairs (DS1 lines).
Table 1-1
AN2016 compartments
Compartment Contents
Equipment AccessNode system, dc power distribution facilities, fiber
termination facilities, environmental controls and the
miscellaneous optional/custom equipment.
Surge protection
center (SPC) and
termination
Copper outside plant VF/DS1 termination, cross connect and
fiber splice closures.
AC AC power distribution box, battery distribution panel, voice
frequency protection
Battery Eight strings of front terminal 12 V batteries options, factory
equipped foil-type battery heater
