Nortel AccessNode 2016 - Standard Equipment (864 Lines)

Ordering information
6-23
User Guide Rel 1.0 Standard May 1999
Standard equipment (864 lines)
This section lists the standard equipment for an AN2016 Cabinet with
connections for 864 VF lines.
Table 6-6 on page 6-23 lists the standard equipment and
Table 6-7 on page 6-27 lists required options for a 864-line AN2016 Cabinet.
For a front view of frame/bay A, B, C, D, E and F, the equipment frame/bay
layouts and mounting positions, see Figure 6-7, Figure 6-2, Figure 6-3,
Figure 6-4, Figure 6-5 and Figure 6-6.
NTNR90AA Distribution power cable used to power up the CDS shelves 1
NTNR90BA Cable kit to power up the CDS shelves 1-7 talk batteries 1
P0902427 Cabinet label kit 1
Required options to order
B01231144 NT5C06CA-3 MPR 25 rectifier module (see Notes 1 and 2) 2 or 3
Note 1:
Insert appropriate number of modules into rectifier shelves NT5C10CP-61 part of NTNR21AA.
Note 2:
Four modules total are required for 2016 lines + (1) for redundancy.
Note 3:
Refer to “Optional battery backup” on page 6-45 for ordering battery string hook up cables,
required when the battery compartment holds the battery backup.
Note 4:
Refer to “ Optional remote monitoring unit” on page 6-44 for ordering RMU test access path
cable when optional RMU NTNR35AA is selected. A cable must be ordered for each additional AN ABM
NTNR10AA.
—end—
Table 6-6
AN2016 Cabinet 864-line equipment (standard)
PEC Description Quantity
A0774668 A0774668 Pad mounting template
Note:
To be ordered ahead of time for site preparation.
1
NTNR01AA includes AN2016 outside plant (OSP) cabinet with heaterpad (3M) 1
A0768446 400 pair VF, 5 pins, field side 26 AWG, 8 ft long 1
A0768447 300 pair VF, 5 pins, field side 26 AWG, 6 ft long 1
A0768448 400 pair VF, 5 pins, field side 26 AWG, 8 ft long 1
—continued—
Table 6-5 (continued)
672- to 2016-line expansion kit equipment (standard) for AN2016 Cabinet
PEC Description Quantity
