Ordering information
6-7
User Guide Rel 1.0 Standard May 1999
Figure 6-6
672, 864 and 1344-line configuration (front view frame/bay F)
AN0039.eps
Front view of bay
CDS 4-1
CDS 5-1
CDS 6-1
CDS 7-1
Fan shelf
ECU unit
28
38
43
53
58
70
Reserved and dedicated
positions for future
expansion
(Note)
Spacer shelf
Note: The following empty spaces are reserved and dedicated only for
future expansion using CDS shelves or future UE 9000 shelves.
