Nortel AccessNode 2016 - Standard Equipment (2016 Lines)

6-36
Ordering information
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Standard equipment (2016 lines)
This section lists the standard equipment for an AN2016 Cabinet with
connections for 2016 VF lines.
Table 6-13 on page 6-36 lists the standard equipment and
Table 6-14 on page 6-40 lists required options for a 2016-line AN2016
Cabinet.
For a front view of frame/bay A, B, C, D, E and F, the equipment frame/bay
layouts and mounting positions, see Figure 6-8, Figure 6-10, Figure 6-11,
Figure 6-4, Figure 6-5 and Figure 6-12.
Table 6-13
AN2016 Cabinet 2016-line equipment (standard)
PEC Description Quantity
A0774668 A0774668 Pad mounting template
Note:
To be ordered ahead of time for site preparation.
1
NTNR01AA includes AN2016 outside plant (OSP) cabinet with heaterpad (3M) 1
A0768446 400 pair VF, 5 pins, field side 26 AWG, 8 ft long 1
A0768447 300 pair VF, 5 pins, field side 26 AWG, 6 ft long 1
A0768448 400 pair VF, 5 pins, field side 26 AWG, 8 ft long 1
A0768449 300 pair VF, 5 pins, field side 26 AWG, 6 ft long 1
A0768450 400 pair VF, 5 pins, field side 26 AWG, 16 ft long 1
A0768451 300 pair VF, 5 pins, field side 26 AWG, 16 ft long 1
A0768452 100 pair Digital, 5 pins, 19 inch mount, field side 24 AWG, 8
ft long
2
A0769355 Power system, battery disconnect panel with eight 30A dc
circuit breakers
1
A0769072 Inside protection mounting brackets 4
A0769076 Outside protection mounting brackets 3
A0769077 U-channel protection mounting brackets 9
A0769087 Splice bars 4
A0769099 Metal conduit raceway 1
NTNR10AA includes AccessNode hardware kit 3
NT4K14AB Breaker interface panel 1
—continued—
