Ordering information
6-27
User Guide Rel 1.0 Standard May 1999
Table 6-7 lists the required options for a 864-line cabinet.
Table 6-8 lists the standard equipment for an expansion kit from 864- to
1344-line cabinet. For the equipment frame/bay layouts and mounting
positions, see Figure 6-8 and Figure 6-9.
Table 6-7
AN2016 Cabinet 864-line required options
CPC PEC Description Quantity
B01231144 NT5C06CA-3 MPR 25 rectifier module (see Notes 1 and 2) 3 or 4
Note 1:
Insert appropriate number of modules into rectifier shelves NT5C10CP-61 part of NTNR21AA.
Note 2:
Order (1) MPR 25 for each AN hardware (672L) + (1) for each OEM stack + (1) for redundancy.
Note 3:
Refer to “Optional battery backup” on page 6-45 for ordering battery string hook up cables,
required when the battery compartment holds the battery backup.
Note 4:
Refer to “ Optional remote monitoring unit” on page 6-44 for ordering RMU test access path
cable when optional RMU NTNR35AA is selected. A cable must be ordered for each additional AN ABM
NTNR10AA.
Table 6-8
864- to 1344-line expansion kit equipment (standard) for AN2016 Cabinet
PEC Description Quantity
NTNR12AA includes AccessNode copper distribution shelf CDS kit 5
Note:
Refer to “Optional battery backup” on page 6-45 for ordering battery string hook up cables,
required when the battery compartment holds the battery backup.
NT4K12AB Copper distribution shelf 1
NT4K1222 Line shelf label kit english 1
Cables, assemblies and kits to order
NT4K86NA Shelf metallic test pair cable assembly, 2 ft long 4
NT4K86NC Shelf metallic test pair cable assembly, 8 ft long 1
NT4K82DC Cable assembly, A/B link VF/T/D, CDS 3 1
NT4K82DD Cable assembly, A/B link VF/T/D, CDS 4 1
NT4K82DE Cable assembly, A/B link VF/T/D, CDS 5 1
NTNR82DF Cable assembly, A/B link VF/T/D, CDS 6 1
NTNR82DG Cable assembly, A/B link VF/T/D, CDS 7 1
NT4K0610 Fan shelf assembly, eight fans 1
NT1W10AA Shelf separator assembly 2
P0902427 Cabinet label kit 1
