6-10
Ordering information
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Figure 6-9
1344-line configuration (front view frame/bay B)
AN0043.eps
CDS 4-2
CDS 5-2
Fan shelf
CDS 6-2
CDS 7-2
Front view of bay
Note: The following empty spaces are reserved and dedicated only for
future expansion using CDS shelves or future UE 9000 shelves.
Reserved and dedicated
positions for future
expansion
(Note)
28
38
43
53
58
70
Spacer shelf
