Ordering information
6-45
User Guide Rel 1.0 Standard May 1999
Table 6-19 lists the optional battery backup and associated cable assembly for
the AN2016 Cabinet.
Table 6-19
Optional battery backup
CPC PEC Description Quantity
A0734525 A0734525 C&D FA-12-100 battery backup, single block kit (see
Notes)
1
A0774151 NTNR95BA Battery string hook-up cable with 5/16 inch lugs used
with A0734525
See Note 2
A0773445 A0773445 East Penn 12AVR100-3ET battery backup, single block
kit (see Notes)
1
A0774150 NTNR95AA Battery string hook-up cable with 1/16 inch lugs used
with A0773445
See Note 2
A0773443 A0773443 Power Battery CSL-12100 battery backup, single block
kit (see Notes)
1
A0774150 NTNR95AA Battery string hook-up cable with 1/16 inch lugs used
with A0773443
See Note 2
Note 1:
The kit includes one battery block and one solid intercell jumper with washers and nuts to
provide continuous operation for 8 hours backup. The kit can also be ordered as spare or replacement.
Note 2:
Hook-up cables must be ordered for linking the battery strings in the cabinet battery
compartment, one for each strings. These (Y) cables include an Anderson connector and two lugs of
the appropriate size to fit the battery terminals.
Note 3:
One string consists of four individual battery blocks. Use the following guidelines for ordering:
672 Lines equipped: four strings are required
864 Lines equipped: five strings are required
1344 Lines equipped: six strings are required
2016 Lines equipped: eight strings are required
