Nortel AccessNode 2016 - Page 139

Ordering information
6-3
User Guide Rel 1.0 Standard May 1999
Figure 6-2
672 and 864-line configuration (front view frame/bay B)
AN0089.eps
Reserved and dedicated
positions for future
expansion
(Note)
Front view
79
64
54
44
32
18
10
01
24.335 reference
1.250
.500
.625
.625
.375
.500
Note: The following empty spaces are reserved and dedicated only for
future expansion using CDS shelves or future UE 9000 shelves.
