Nortel AccessNode 2016 - Page 134

5-18
Maintenance
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Figure 5-12
LED functions
AN0111.eps
System
Mode
Thermistor
Intrusion
Fuse
High temperature
Fan shelf
Fan shelf
Not used
Not used
Not used
Not used
Not used
Not used
HX fan 6
HX fan 5
HX fan 4
HX fan 3
HX fan 2
HX fan 1
Reset
Override
