5-16
Maintenance
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
J8 1
2
3
4
Ground
-48 Vdc
Tachometer
Control
J10 1
2
3
4
Ground
-48 Vdc
Tachometer
Control
J12 1
2
3
4
Ground
-48 Vdc
Alarm
Control
J14 1
2
3
Ground
-48 Vdc
Alarm
J15 1
2
3
Ground
-48 Vdc
Alarm
J16 1
2
3
Ground
-48 Vdc
Alarm
J17 1
2
3
Ground
-48 Vdc
Alarm
J18 1
2
3
Ground
-48 Vdc
Alarm
J19 1
2
3
Ground
-48 Vdc
Alarm
J20 1
2
3
Ground
-48 Vdc
Alarm
—end—
Table 5-2 (continued)
Connector Description J1 through J20
