2-8
Equipment
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Figure 2-4
Heat exchanger air flow
AN0091.eps
Cabinet side view
of heat exchanger
Heat exchanger
Air exhaust
from roof
Air intake from
battery compartment
Battery compartment
Close loop air circulation
within electronics equipment
chamber
