2-24
Equipment
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Figure 2-15
864-line configuration (front view)
AN0055.eps
LCAP
BIP
ABM 2
Fan shelf
CDS 1 (2)
CDS 2 (2)
Heat exchanger plenum Heat exchanger plenum Heat exchanger plenum
Future expansion
Future expansion Future expansion
Front of cabinet
Frame/bay A Frame/bay C Frame/bay B
SPC compartment AC compartment Battery compartment
