Installation guidelines
3-27
User Guide Rel 1.0 Standard May 1999
Procedure 3-8 (continued)
Installing the cable in the split sleeve
Step Action
11
Apply locally approved sealing compound around the opening in the split
base panel. Place sealing compound along the joint between the front and
rear split panel and around the split cable sleeve seam.
12
Install any remaining cables in the front split cable sleeves.
13
Install the front split cable sleeve plate removed previously. Slide nozzles up
over the two front split cable sleeves, then install and tighten the upper and
lower hose clamps.
14
Continue the cabinet installation process (see Procedure 3-9, “Connecting
the earth ground to the cabinet”).
—end—
