UDACT Instruction Manual PN 50050:H 09/16/2002
AM2020/AFP1010/INA
Notes:
1. Use of a UDACT with the AFP-200, System 500 or System 5000 will not alter the assignment of
the first eight red LEDs on the annunciator. The first Red LED annunciates alarms while the next
seven Red LEDs are not used.
2. When using a UDACT with the AM2020/AFP1010/INA, the first Red LED on an annunciator is
used to annunciate alarms while LEDs 2 through 8 are not used.
Yellow Annunciator
LED
Assignment
Without UDACT
Assignment
With UDACT
1 Programmable System Trouble (less AC
loss, batt. & supv.)
2 Programmable Not Used
3 Programmable Program Mode
4 Programmable Supervisory
5 Programmable Not Used
6 Programmable Maintenance Alert (future
use)
7 Programmable Low Battery/No Battery
8 Programmable AC Fail
