Ademco Contact ID Format
UDACT Instruction Manual PN 50050:H 09/16/2002 41
Ademco Contact ID Format
Primary Number
If 'E' is entered for address 16, the following data is automatically programmed for the primary phone number event
codes.
Enter a '000' for the data setting to disable the report.
Table 8 Ademco Contact ID, Primary Number
Notes:
1) Zero entries prevent the transmission of the report to the Central Station.
2) Refer to Contact ID program locations 64 - 68.
3) The identification of the zone/device number is automatically transmitted by the UDACT and is added to the main
event code. See Table 5-3 for more information.
4) For control panels; System 500, System 5000, AFP-200, AFP-400, AFC-600, NFS-640, AFP1010, AM2020, INA,
NFS-3030, and NCA the factory default event code is 110 and reprogrammable. The AFP-400 and AFP-100 are
unique in point reporting mode in that only the control module report codes are programmable. The factory setting of
report code 111 is fixed for addressable smoke detectors and cannot be changed.
5) AFP-200 applications transmit by zone, not by point.
6) The Group # is automatically incremented for AM2020/AFP1010/INA, NFS-3030 and NCA applications.
Address Description
Setting
1
Group #
6
Sensor #
69-71 Primary# General Alarm Code 110 00
000
2
72-74
Primary # Zone/Point Alarm Code
5
110
4
00
Note
3
75-77 Primary # General Supervisory Code 200 00
000
2
78-80
Primary # Zone/Point Supervisory Code
5
200 00
Note
3
81-83 Primary # General Fault Code 300 00
84-86 Primary # AC Fault Code 301 00
87-89
Primary # Zone/Point Fault Code
5
380 00
Note
3
90-92 Primary # Low Battery Fault Code 302 00
93-95 Primary # Telco Primary Line Fault Code 351 00
96-98 Primary # Telco Secondary Line Fault Code 352 00
99-101 Primary # NAC Fault Code 321 00
102-104 Primary # Comm. Trouble Primary # Code 354 00
105-107 Primary # Comm. Trouble Secondary # Code 354 00
108-110 Primary # 485 Comm. Trouble Code 300 00
111-113 Primary # System Off Normal Code 308 00
114-116 Primary # UDACT Off Normal Code 350 00
117-119 Primary # System 24 Hour Test 602 00
120-122 Primary # System 24 Hour Test w/active event 608 00
123-125 Primary # Manual Test Message 601 00
