Installation
UDACT Instruction Manual PN 50050:H 09/16/2002 19
Installation and Wiring
Installation
Options
The UDACT is either installed internally in the FACP cabinet or in a remote cabinet. The following
table contains information specific to each FACP that is compatible with the UDACT. See "Internal
Installation" on page 20 for instructions on internal installation and "Remote Installation" on page 22
for instructions on remote installation. Any additional information required for installing the UDACT in
a specific Fire Alarm Control Panel will be found in the appropriate appendix relating to that panel.
Table 2 Installation Options
Fire Alarm
Control Panel
Cabinet Style Where Installed
AFP-100 SBB-1 Internal or Remote
AFP-200 CAB-200AA Remote Only
AFP-300/AFP-400 CAB-400AA Remote Only
CAB-3/4 Series Internal or Remote
AFC-600 CAB-600AA Remote Only
CAB-3/4 Series Internal or Remote
System 500 CAB-500 Remote Only
System 5000 CAB-3/4 Series Internal or Remote
AM2020/AFP1010 CAB-3/4 Series Internal or Remote
INA CAB-3/4 Series Internal or Remote
NCA CAB-3/4 Series Internal or Remote
NFS-640 CAB-3/4 Series Internal or Remote
NFS-3030 CAB-3/4 Series Internal or Remote
