Data Reporting Structure
UDACT Instruction Manual PN 50050:H 09/16/2002 61
Ademco Contact ID
The reporting structure for the Ademco Contact ID format is as follows:
SSSS 18 QXYZ GG CCC
Table 14 Ademco Contact ID Reporting Structure
Note: For general reports (alarm, trouble and supervisory), the GG and CCC fields are transmitted as 00 and 000
unless changes to addresses 64-65 and 66-68 are made.
64 - 65 = Loop number (GG), (factory default is 00)
66 - 68 = Device/Zone number (CCC) for General Alarm, Fault or Supervisory messages (factory default is 000).
A typical printout of alarm and trouble reports in the Ademco Contact ID Reporting Structure follows:
Note: In the sample report, SD46 refers to smoke detector at address 46 or on zone 46.
Note: 18, which is used in the reporting structure to identify the transmission as Contact ID, is not printed out in the
alarm and trouble report.
Note: Q, which is the Event Qualifier for the reporting structure, is printed out in the report as an E for New Event or R
for New Restore.
Note: CCCC, the first C is not transmitted by the UDACT but is printed by the Central Station Receiver printer output.
Continued on the next page...
SSSS = Four digit Subscriber ID (addresses 17 - 20 and 43 - 46)
18
=
Identifies transmission as Contact ID to the receiver
at the Central Station
Q = Event Qualifier; 1 = New Event, 2 = New Restore
XYZ = Event Code (shown in Table 4 to Table 9)
GG = Group or Loop number
CCC = Device or Zone number
Time Date
Rcvr/
Line ID
SSSS QXYX GG CCCC
11:28 10/14 11 7777 E110 00 C000 General Alarm
11:28 10/14 11 7777 E111 00 C046 Alarm SD46
11:28 10/14 11 7777 E300 00 C000 General Trouble
11:28 10/14 11 7777 E380 00 C046 Trouble SD46
11:28 10/14 11 7777 R110 00 C000 General Alarm Restore
11:28 10/14 11 7777 R111 00 C046 Alarm SD46 Restore
11:28 10/14 11 7777 R300 00 C000 General Trouble Restore
11:28 10/14 11 7777 R380 00 C046 Trouble SD46 Restore
